INSTRUMENT VALVES
The Sabre range of instrument valves, manifolds and accessories has been specifically developed to meet the demanding needs of our clients. Delivering long term in-service reliability and minimum life-time costs, Sabre instrument valves and manifolds are supplied as standard with the following certification.
- Full material traceability
- NACE compliance
- 100% functional pressure testing
- Functional Test Certification
- Letter of Conformity
- PED CE marking where applicable
-
10mm CRYOGENIC INTEGRAL BALL VALVE DOUBLE BLOCK & BLEED
The precision-made Cryogenic Bolted Gland Integral Ball Valve Double Block & Bleed utilising floating soft seat design with extended bolted gland isolation valves featuring a lipseal and a compact unit size with fewer potential leak paths. Available in a wide range of different materials to suit various low temperature applications.
-
10mm Integral Ball Valve Double Block & Bleed
The precision-made Integral Ball Valve Double Block & Bleed utilising floating soft seat design and a compact unit size with fewer potential leak paths. Available in a wide range of different materials to suit various applications.
-
14mm BOLTED GLAND INTEGRAL BALL VALVE DOUBLE BLOCK & BLEED
The precision-made bolted gland Integral Ball Valve Double Block & Bleed utilising floating soft seat design with bolted gland isolation valves featuring a lipseal and a compact unit size with fewer potential leak paths. Available in a wide range of different materials to suit various applications.
-
BMVX1 Flange x Flange / Flange x Threaded
Single Isolation Ball valve (with optional Bleed using split stem non-rotating needle tip). Utilising Soft Seated Floating Ball isolation for bubble tight sealing capabilities at extreme pressures.
-
FVX1 Female/Female, FVX2 Male/Female
The precision made FVX1 & FVX2 single isolation hand valve offer a high-pressure design with “One Piece” Integral Stuffing Box & Body the valve provides strength and material hardness for extreme operating conditions.
-
FVX1A Female/Female, FVX2A Male/Female
The precision made FVX1A & FVX2A single isolation angle pattern hand valve offers a high-pressure design with “One Piece” Integral Stuffing Box & Body. The valve provides strength and material hardness for extreme operating conditions.
-
HMX1 – 2 Valve Manifold
For static pressure measurement with D.P. style, absolute and gauge pressure transmitters. A compact 2 valve manifold designed to accommodate larger gauges within the IEX1 enclosure combining isolating, calibrating and venting facilities in a single unit providing a threaded instrument connection for remote mounting instruments.
-
HMX2 – 2 Valve Manifold
For static pressure measurement with D.P. style, absolute and gauge pressure transmitters. A compact 2 valve manifold combining isolating, calibrating and venting facilities in a single unit providing a Direct Flanged instrument connection for remote mounting instruments. also available with threaded instrument connections for remote mounting instruments.
-
HMX3 – 3 Valve Manifold
For general liquid and gas measurement applications using D.P. transmitters. A 3-valve manifold combining 2 isolating and 1 equalising valves in a single compact unit providing easy instrument isolation and zeroing. Provided with instrument flange mounting detail on 54mm centres (other centre distances are available on request). Also available with integral steam channel, for greater […]
QUALITY ASSURANCE
In 1982 we received the BS5750 manufacturing standard proving our quality has always been one of our core principals. We have been ISO9001 accredited since 2007, additionally many of our individual products also hold many industry renowned accreditations and are tested for a multitude of severe environments. Find out more about Alco Valve’s quality assurance below.
Sabre Approvals
Together with our many quality accreditations, these approvals give you the peace of mind of buying from a recognised, established global
supplier.
Our aim is to provide high-quality, reliable equipment for optimum reliability and service life. The fact that our valves and equipment are specified by many of the world’s leading oil, offshore and power companies speaks volumes for their effectiveness.
The features of our high-quality valves
